Chapter 1: Safety

1.1: Safety Information

It is the sole responsibility of the purchaser of LIFE FITNESS products to read the owner’s manual and warning labels and instruct all individuals, whether they are the end user or supervising personnel, on proper usage of the equipment.

UNDERSTANDING EACH AND EVERY WARNING TO THE FULLEST IS IMPORTANT. IF ANY OF THESE WARNINGS ARE UNCLEAR, CONTACT LIFE FITNESS CUSTOMER SERVICE IMMEDIATELY AT 1-800-351-3737.

This equipment is categorized as class S per EN ISO 20957-1. As such this equipment is only intended for commercial, institutional and/or studio facilities. It is not intended for home use. Contact LIFE FITNESS with any questions regarding this classification.

It is recommended that all users of LIFE FITNESS exercise equipment be informed of the following information prior to use.

1.2: Access Control

LIFE FITNESS recommends that all commercial fitness equipment be used in a supervised area. It is recommended that the equipment be located in an access controlled area. Control is the responsibility of the facility owner.

1.3: Installation

SECURING EQUIPMENT - LIFE FITNESS requires that all equipment be secured to a solid, level surface to stabilize it and eliminate rocking or tipping over. This must be performed by a licensed contractor. See Bolt to Floor Guidelines for installation procedure.

1.4: Proper Usage

  • Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that LIFE FITNESS equipment is used properly to avoid injury.
  • Injuries may result if exercising improperly or excessively. It is recommended that all individuals consult a physician prior to commencing an exercise program. If at any time during exercise you feel faint, dizzy or experience pain, STOP EXERCISING and consult your physician.
  • Keep body parts (hands, feet, hair, etc.), clothing and jewelry away from moving parts to avoid injury.
  • When adjusting any seat, knee hold down pad, range of motion limiter, foothold pad, pulley or any other type of adjuster, make certain that the adjusting pin is fully engaged in the hole to avoid injury.

1.5: Inspection

  • DO NOT use or permit use of any equipment that is damaged and/or has worn or broken parts. For all LIFE FITNESS equipment use only replacement parts supplied by LIFE FITNESS .
  • Cables and belts pose an extreme liability if used when frayed. Always replace any cable at first sign of wear (consult LIFE FITNESS if uncertain).
  • Routinely inspect all accessory clips that join attachments to the cables and replace them at the first sign of wear.
  • MAINTAIN LABELS AND NAME PLATES - Do not remove labels for any reason. They contain important information. If unreadable or missing, contact LIFE FITNESS for a replacement.
  • EQUIPMENT MAINTENANCE - Preventative maintenance is the key to smooth operating equipment as well as to keep your liability to a minimum. Equipment needs to be inspected at regular intervals.
  • Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so. LIFE FITNESS will provide service and maintenance training at our corporate facility upon request or in the field if proper arrangements are made.
  • Before any use, examine all accessories approved for use with the LIFE FITNESS equipment for damage or wear.
  • DO NOT ATTEMPT TO USE OR REPAIR ANY ACCESSORY APPROVED FOR USE WITH THE LIFE FITNESS EQUIPMENT WHICH APPEARS TO BE DAMAGED OR WORN.

1.6: Operating Warnings

Warning: This product can expose you to chemicals including Di-isobutyl Phthalate, which is known to the State of California to cause birth defects or other reproductive harm, and Antimony Trioxide, which is known to the State of California to cause cancer. For more information go to http://www.P65Warnings.ca.gov
  • It is the purchaser’s sole responsibility to properly instruct its end users and supervising personnel as to the proper operating procedures of all equipment.
  • Keep children away from strength equipment. Parents or others supervising children must provide close supervision of children if the equipment is used in the presence of children.
  • Do not allow users to wear loose fitting clothing or jewelry while using equipment. It is also recommended to have users secure long hair back and up to avoid contact with moving parts.
  • All bystanders must stay clear of all users, moving parts and attached accessories and components while machine is in operation.

1.7: Selectorized Weight Stack Systems

  • Use only weight selector pins supplied by LIFE FITNESS on weight stacks. Substitutes are forbidden.
  • Fully insert weight selector pins. Partial insertion can cause weights to fall unexpectedly.
  • Never pin the weight stack in an elevated position.
  • Never remove selector pin if any weights are suspended.
  • Never attempt to release jammed weights or parts.
  • Never use dumbbells or other means to incrementally increase the weight resistance. Use only those means provided by LIFE FITNESS .

1.8: Warnings and Cautions

Warning labels indicate a potentially hazardous situation that could result in serious injury or death if the precautions are not observed.

Caution labels indicate a potentially hazardous situation that could result in serious injury or damage to machine if the precautions are not observed.

Contact Customer Support Services to replace any worn or damaged labels.

1.9: Product Labels

General Warning Label
Body Weight Strap Training Label
Carriage Label
Serial Number Label
Weight Stack Label Pinch Hazard Label
Power Pivot Label

1.10: Label Locations

Important: Verify all labels / decals listed are placed on the product and in the location shown. Replace any missing or damaged labels.

1.10.1: Attached Cable Crossover (PP-ACO)

Description Qty
1 Pinch Hazard Label 4
2 Carriage Label 2
3 Weight At Handle Label 2
4 Serial Number Label 1
5 Body Weight Strap Training Label 2
6 General Warning Label 1
7 Placard 2

1.10.2: Free Standing Cable Crossover (PP-ACOFS)

Description Qty
1 Body Weight Strap Training Label 4
2 Carriage Label 2
3 Pinch Hazard Label 4
4 Weight At Handle Label 2
5 General Warning Label 2
6 Serial Number Label 1
7 Placard 2

1.10.3: Dip/Chin Assist (PP-ADC)

Description Qty
1 Serial Number Label 1
2 Placard 1

1.10.4: Adjustable Cable Column (PP-AP)

Description Qty
1 Pinch Hazard Label 1
2 Carriage Label 1
3 Weight At Handle Label 1
4 Serial Number Label 1
5 Placard 1

1.10.5: Adjustable Pulley 4:1 (PP-AP41)

Description Qty
1 Pinch Hazard Label 1
2 Carriage Label 1
3 Weight At Handle Label 1
4 Serial Number Label 1
5 Placard 1

1.10.6: Embedded Cable Crossover (PP-AXO)

Description Qty
1 Pinch Hazard Label 4
2 Carriage Label 2
3 Weight At Handle Label 2
4 Serial Number Label 1
5 Placard 2

1.10.7: Crossover Boom (PP-BM)

Description Qty
1 Serial Number Label 1

1.10.8: Boxing (PP-BX)

Description Qty
1 Serial Number Label 1
2 Placard 1

1.10.9: Core (PP-CORE)

Description Qty
1 General Warning Label 1
2 Body Weight Strap Training Label 4
3 Serial Number Label 1

1.10.10: Dip (PP-DIP)

Description Qty
1 Serial Number Label 1

1.10.11: Dual Pulley High (PP-DPH)

Description Qty
1 Serial Number Label 1
2 Weight At Handle Label 1
3 Placard 1

1.10.12: Dual Pulley Low (PP-DPL)

Description Qty
1 Weight At Handle Label 1
2 Serial Number Label 1
3 Placard 1

1.10.13: Attached High Low Crossover (PP-FCO)

Description Qty
1 Weight At Handle Label 2
2 Serial Number Label 1
3 Body Weight Strap Training Label 2
4 General Warning Label 1
5 Placard 2

1.10.14: Embedded High Low Crossover (PP-FXO)

Description Qty
1 Weight At Handle Label 2
2 Serial Number Label 1
3 Placard 2

1.10.15: Handle Accessory Rack (PP-HAR)

Description Qty
1 Serial Number Label 1

1.10.16: High Low (PP-HL)

Description Qty
1 Weight At Handle Label 1
2 Serial Number Label 1
3 Placard 1

1.10.17: Lat Pull (PP-LP)

Description Qty
1 Pinch Hazard Label 1
2 Serial Number Label 1
3 Placard 1

1.10.18: Dual Handle Lat Pull (PP-LPD)

Description Qty
1 Weight At Handle Label 1
2 Pinch Hazard Label 1
3 Serial Number Label 1
4 Placard 1

1.10.19: Power Pivot (PP-PP)

Description Qty
1 Serial Number Label 1
2 Power Pivot Label 1
3 Placard 1

1.10.20: Rope Pull - Power Pivot (PP-RP)

Description Qty
1 Power Pivot Label 1
2 Serial Number Label 1
3 Placard 1

1.10.21: Rope Pull (PP-RPL)

Description Qty
1 Serial Number Label 1
2 Placard 1

1.10.22: Low Row (PP-RW)

Description Qty
1 Serial Number Label 1
2 Placard 1

1.10.23: Dual Handle Low Row (PP-RWD)

Description Qty
1 Weight At Handle Label 1
2 Serial Number Label 1
3 Placard 1

1.10.24: Stall Bars (PP-SB)

Description Qty
1 Serial Number Label 1
2 Placard 1

1.10.25: Storage Station (PP-SC)

Description Qty
1 Serial Number Label 1

1.10.26: Step (PP-STP)

Description Qty
1 Serial Number Label 1

1.10.27: Storage Connector (PP-SX)

Description Qty
1 Serial Number Label 1

1.10.28: Triceps Pushdown (PP-TP)

Description Qty
1 Serial Number Label 1
2 Placard 1

Chapter 2: Product Information

2.1: Specifications

Machine Weight: 57 lbs. 26 kg.
Size (L x W x H): in. = 20 x 19 x 46 cm = 50 x 48 x 116
Live Area (L x W): in. = 44 x 19 cm = 112 x 48
Storage Weight: 180 lbs. 82 kg.
Max Load: 8 pairs of dumbbells, 5-20 lbs.

Chapter 3: Assembly

3.1: Barbell Rack Assembly

3.1.1: Hardware and Required Tools

Hardware
Hardware
Item Description Qty
1 M10 x 1.5 screw, 100mm 24
2 M10 x 1.5 screw, 70mm 2
3 M10 x 1.5 screw, 20mm 4
4 Torx screw 16
5 Nut 2
6 Endcap - Grey 8
Endcap - Yellow 8
Endcap - Green 8
Endcap - Blue 8
7 SAE #10 washer 16
8 3/8 in. washer 32
9 Plug 8
10 Foot pad 4
11 Base cap 2
12 Upright cap 4
13 Rack Base 1
14 Row 6
15 Rack Upright 2

Required Tools:

  • 7 mm Allen wrench
  • T25 Torx wrench
  • 17 mm wrench
  • 17 mm socket wrench
  • Rubber mallet

3.1.2: Barbell Rack Assembly Procedure

Locate the part ID on the components before assembling.
  1. Attach the foot pads to the rack base.
    Item Description Qty.
    1 Torx screw 16
    2 SAE #10 washer 16
    3 Foot pad 4
    4 Base 1

  2. Install the base caps into the base.
    Item Description Qty.
    1 Base cap 2
    2 Base 1
  3. Install the upright caps into the uprights.
    Item Description Qty.
    1 Upright cap 4
    2 Uprights 2
  4. Attach the rack uprights to the rack base.
    Item Description Qty.
    1 M10 x 1.5 screw, 70mm 2
    2 3/8 in. washer 2
    3 Nut 2
    4 Rack upright (LT) 1
    5 Rack upright (RT) 1
    6 Rack base 1

  5. Lift the assembly, and place into position.
  6. Attach the rack uprights to the rack base.
    Item Description Qty.
    1 M10 x 1.5 screw, 20mm 4
    2 3/8 in. washer 4

  7. Attach row 1 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 4
    2 3/8 in. washer 4
    3 Row 1 1

  8. Attach row 2 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 4
    2 3/8 in. washer 4
    3 Row 2 1

  9. Attach row 3 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 4
    2 3/8 in. washer 4
    3 Row 3 1

  10. Attach row 4 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 4
    2 3/8 in. washer 4
    3 Row 4 1

  11. Attach row 5 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 4
    2 3/8 in. washer 4
    3 Row 5 1

  12. Attach row 6 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 4
    2 3/8 in. washer 4
    3 Row 6 1

  13. Tighten the screws, and install the plugs.
    Item Description Qty.
    1 Plug 4

  14. Tighten the screws, and install the plugs.
    Item Description Qty.
    1 Plug 2

  15. Tighten the screws to 10-12 ft. lbs. (13-16 Nm).
  16. Install the endcaps.
    Item Description Qty.
    1 Yellow endcap 8
    2 Green endcap 8
    3 Blue endcap 8
    4 Grey endcap 8

3.2: Dumbbell Rack Assembly

3.2.1: Hardware and Required Tools

Hardware
Parts included in the kit
Hardware
Item Description Qty
1 M10 x 1.5 screw, 100mm 20
2 M10 x 1.5 screw, 70mm 2
3 M10 x 1.5 screw, 20mm 4
4 Torx screw 16
5 Nut 2
6 Adhesive label - Yellow 7
Adhesive label- Green 7
Adhesive label - Orange 7
Adhesive label - Red 7
Adhesive label - Blue 7
Adhesive label - Purple 7
7 SAE #10 washer 16
8 3/8 in. washer 28
9 Plug 8
10 Foot pad 4
11 Base cap 2
12 Upright cap 4
13 Rack Base 1
14 Row 5
15 Rack Upright 2

Required Tools:

  • 7 mm Allen wrench
  • T25 Torx wrench
  • 17 mm wrench
  • 17 mm socket wrench
  • Rubber mallet

3.2.2: Dumbbell Rack Assembly Procedure

Locate the part ID on the components before assembling.
  1. Attach the foot pads to the rack base.
    Item Description Qty.
    1 Torx screw 16
    2 SAE #10 washer 16
    3 Foot pad 4
    4 Rack base 1

  2. Install the base caps into the base.
    Item Description Qty.
    1 Base cap 2
    2 Rack base 1
  3. Install the caps.
    Item Description Qty.
    1 Cap 4
    2 Rack upright 2
  4. Attach the rack uprights to the rack base.
    Item Description Qty.
    1 M10 x 1.5 screw, 70mm 2
    2 3/8 in. washer 2
    3 Nut 2
    4 Rack upright (LT) 1
    5 Rack upright (RT) 1
    6 Rack base 1

  5. Lift the assembly, and place into position.
  6. Attach the rack uprights to the rack base.
    Item Description Qty.
    1 M10 x 1.5 screw, 20mm 4
    2 3/8 in. washer 4

  7. Attach row 1-4 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 16
    2 3/8 in. washer 16
    3 Row 1-4 4

  8. Attach row 5 to the rack uprights.
    Item Description Qty.
    1 M10 x 1.5 screw, 100mm 4
    2 3/8 in. washer 4
    3 Row 5 1

  9. Tighten the screws.

    10-12 ft. lbs. (13-16 Nm)

  10. Tighten the screws, and install the plugs.
    Item Description Qty.
    1 Plug 4

    15-20 ft. lbs. (20-27 Nm)

  11. Tighten the screws, and install the plugs.
    Item Description Qty.
    1 Plug 2

    15-20 ft. lbs. (20-27 Nm)

  12. Install the adhesive labels.
    Item Description Qty.
    1 Blue adhesive label 4
    2 Yellow adhesive label 7
    3 Green adhesive label 7
    4 Orange adhesive label 7
    5 Red adhesive label 7
    6 Purple adhesive label 3

3.3: Kettlebell Rack Assembly

3.3.1: Hardware and Required Tools

Hardware
Parts included in the kit
Hardware
Item Description Qty
1 M10 x 1.5 screw, 100mm 12
2 M10 x 1.5 screw, 70mm 2
3 M10 x 1.5 screw, 20mm 4
4 Torx screw 16
5 Nut 2
6 SAE #10 washer 16
7 3/8 in. washer 20
8 Plug 8
9 Foot pad 4
10 Upright cap 4
11 Base cap 2
12 Tray liner 4
13 Tray 3
14 Rack Base 1
15 Rack Upright 2

Required Tools:

  • 7 mm Allen wrench
  • T25 Torx wrench
  • 17 mm wrench
  • 17 mm socket wrench
  • Rubber mallet

3.3.2: Kettlebell Rack Assembly Procedure

Locate the part ID on the components before assembling.
  1. Attach the foot pads to the rack base.
    Item Description Qty.
    1 Torx screw 16
    2 Washer, SAE #10 16
    3 Foot pad 4

  2. Install the base caps into the base.
    Item Description Qty.
    1 Base cap 2
  3. Install the caps.
    Item Description Qty.
    1 Cap 4
    2 Upright 2
  4. Attach the rack uprights to the rack base.
    Item Description Qty.
    1 M10 x 1.5 screw, 70mm 2
    2 3/8 in. washer 4
    3 Nut 2
    4 Rack upright (LT) 1
    5 Rack upright (RT) 1
    6 Rack base 1

  5. Lift the assembly, and place into position.
  6. Attach the rack uprights to the rack base.
    Item Description Qty.
    1 M10 x 1.5 screw, 20mm 4
    2 3/8 in. washer 4

  7. Attach tray 1-3 to the rack uprights, and tighten the screws.
    Item Description Qty.
    1 3/8 in. washer 12
    2 M10 x 1.5 screw, 100mm 12

    10-12 ft. lbs. (13-16 Nm)

  8. Tighten the screws, and install the plugs.
    Item Description Qty.
    1 Plug 4

    15-20 ft. lbs. (20-27 Nm)

  9. Tighten the screws, and install the plugs.
    Item Description Qty.
    1 Plug 2
  10. Install the tray liners.
    Item Description Qty.
    1 Tray liner 4

Chapter 4: Warranty

4.1: What is Covered

This Life Fitness commercial exercise equipment product is warranted to be free of all defects in material and workmanship.

4.2: Who is Covered

The original purchaser or any person receiving the product as a gift from the original purchaser.

4.3: Who Pays Transportation and Insurance For Service

If the Product or any covered part must be returned to a service facility for repairs, We, Life Fitness , will pay all transportation and insurance charges for the first year. You are responsible for transportation and insurance charge after the first year.

4.4: What We Will Do To Correct Covered Defects

We will ship to you any new or rebuilt replacement part or component, or at our option, replace the Product. Such replacement parts are warranted for the remaining portion of the original warranty period.

4.5: What is Not Covered

Any failures or damage caused by unauthorized service, misuse, accident, negligence, improper assembly or installation, debris resulting from any construction activities in the Product’s environment, rust or corrosion as a result of the Product’s location, alterations or modifications without our written authorization, or by failure on your part to use, operate and maintain the Product as set out in your Operation Manual.

All terms of this warranty are void if this product is moved beyond the continental borders of the United States of America (excluding Alaska, Hawaii and Canada) and are then subject to the terms provided by that country’s local authorized Life Fitness representative.

4.6: Owner's Manual

It is VERY IMPORTANT THAT YOU READ THIS MANUAL before operating the Product. Remember to perform the periodic maintenance requirements specified in the Manual to assure proper operation and your continued satisfaction.

4.7: Exclusive Warranty

THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND ALL OTHER OBLIGATIONS OR LIABILITIES ON OUR PART. We neither assume nor authorize any person to assure for us any other obligation or liability concerning the sale of this Product. Under no circumstances shall we be liable under this warranty, or otherwise, of any damage to any person or property, including any lost profits or lost savings, for any special, indirect, secondary, incidental or consequential damages of any nature arising out of the use of or inability to use this Product. Some states do not allow the exclusion or limitation of implied warranties or of liability for incidental or consequential damages, so the above limitations or exclusions may not apply to you. Warranty coverages and terms may differ outside the United States. Please contact the Life Fitness office servicing your country (contact information found at the front of this manual) or visit the applicable local Life Fitness website to receive the specific warranty information for your country.

4.8: Changes in Warranty Not Authorized

No one is authorized to change, modify or extend the terms of this limited warranty.

4.9: Effects of State Laws

This warranty gives you specific legal rights, and you may have other rights which vary from state to state and country by country.

4.10: Warranty Coverage

Note: There is no warranty coverage for labor on Strength Products.
Item 5 Years 3 Years 1 Year 90 Days
Frame X
Weight Plates/Dumbbells   X
Barbells     X
Kettlebells     X
Hardware / Mechanical       X
Barbell collars       X
Items Not Specified       X

4.11: How to Obtain Product Service

For CUSTOMER Service within the United States and Canada: 1-800-351-3737 or customersupport@lifefitness.com

Please call Monday through Friday from 7:00 a.m. to 6:00 p.m. Central Standard Time, and tell them your name, address, and serial number of your Product. They will tell you how to get a replacement part, or if necessary, arrange for service where your Product is located or advise you on how and where to ship the Product for service. Before shipping:

  1. Obtain a Return Authorization Number (RA#) from Customer Support Services
  2. Securely pack your Product (use the original shipping carton, if possible)
  3. Write the RA# on the outside of the carton
  4. Insure the Product
  5. Include a letter explaining the defect or problem and a copy of your proof of purchase if you believe the service is covered by warranty.

Return address:

Life Fitness World Headquarters

Attn: CSS Help Desk

10601 W Belmont Ave

Franklin Park, IL 60131

For Product Service Internationally see contact information listed on page two of this manual.

Chapter 5: Maintenance

5.1: Maintenance Schedule

ACTION DAILY WEEKLY MONTHLY AS NEEDED
WAX
Frames       X
INSPECT
Paint     X
Hardware   X
Frame   X
Wax
  • Frames with a standard, non-abrasive, wax finish.
Inspect
  • Hardware. Check for loosening. Tighten as required.
  • Frames. Inspect for wear and damage.
  • For paint chips. Fill in immediately with manufacturers touch-up paint.
Once a Week
  • Visually inspect all hardware for loosening, tampering or wear.
Once a Month
  • Inspect hardware on all machines and tighten any bolts or nuts that may have loosened over the life of the product.
Notes
  • Use polishing compound (such as car wax) and remove shoe scuffs from powder coated surfaces as necessary.
Approved and Compatible Cleaners

Two preferred cleaners have been approved by reliability experts: PureGreen 24 and Gym Wipes. Both cleaners will safely and effectively remove dirt, grime and sweat from equipment. PureGreen 24 and the Antibacterial Force formula of Gym Wipes are both disinfectants that are effective against MRSA and H1N1.

PureGreen 24 is available in a spray which is convenient to use. Apply the spray to a microfiber cloth and wipe down the equipment. Use PureGreen 24 on the equipment for at least 2 minutes for general disinfection purposes and at least 10 minutes for fungus and viral control.

Gym Wipes are large, durable pre-moistened wipes to use on the equipment before and after workouts. Use Gym Wipes on the equipment for at least 2 minutes for general disinfection purposes.

Contact Customer Support Services to order these cleaners (1-800-351-3737 or email: customersupport@lifefitness.com).

Mild soap and water or a mild non-abrasive household cleaner can also be used to clean the display and all exterior surfaces. Use a soft microfiber cloth only. Apply the cleaner to the microfiber cloth before cleaning. DO NOT use ammonia or acid based cleaners. DO NOT use abrasive cleaners. DO NOT use paper towels. DO NOT apply cleaners directly to the equipment surfaces.

Removal of Paint, Marking Pens, or Labels
  • Butyl cellosolve works well for removal of paints, marking pen inks, lipstick, etc.
  • Labels, stickers, etc. may be removed using kerosene. When the solvent will not penetrate sticker material, apply heat (hair dryer) to soften the adhesive and promote removal. GASOLINE SHOULD NOT BE USED.

5.3: Wax

Frames with a standard, non-abrasive, wax finish.

5.4: Inspect

Examine the following for damage and wear:

  • Dumbbells
  • Frame
  • Weight plates
  • Kettlebells
  • Barbells - Inspect for burrs or sharp edges.
  • Hardware - Inspect for loosening. Tighten as required.
  • Paint - Fill all paint chips with Life Fitness touch-up paint.

5.5: Approved and Compatible Cleaners

Two preferred cleaners have been approved by reliability experts: PureGreen 24 and Gym Wipes. Both cleaners will safely and effectively remove dirt, grime and sweat from equipment. PureGreen 24 and the Antibacterial Force formula of Gym Wipes are both disinfectants that are effective against MRSA and H1N1.

PureGreen 24 is available in a spray which is convenient for gym staff to use. Apply the spray to a microfiber cloth and wipe down the equipment. Use PureGreen 24 on the equipment for at least 2 minutes for general disinfection purposes and at least 10 minutes for fungus and viral control.

Gym Wipes are large, durable pre-moistened wipes to use on the equipment before and after workouts. Use Gym Wipes on the equipment for at least 2 minutes for general disinfection purposes.

Contact Customer Support Services to order these cleaners (1-800-351-3737 or email: customersupport@lifefitness.com).

Mild soap and water or a mild non-abrasive household cleaner can also be used to clean the display and all exterior surfaces. Use a soft microfiber cloth only. Apply the cleaner to the microfiber cloth before cleaning. DO NOT use ammonia or acid based cleaners. DO NOT use abrasive cleaners. DO NOT use paper towels. DO NOT apply cleaners directly to the equipment surfaces.

5.6: Remove of Paint, Marking Pen, and Labels

Butyl cellosolve works well for removal of paints, marking pen inks, lipstick, etc.

Labels, stickers, etc. may be removed using kerosene. When the solvent will not penetrate sticker material, apply heat (hair dryer) to soften the adhesive and promote removal. GASOLINE SHOULD NOT BE USED.
